FT - H75VK Cartridge Seals
- Operating Limits: ● Temperature:-40℃ - +220℃ ● Pressure：≤ 40bar ● Speed: ≤ 23m/s ● Shaft size: 25mm - 100mm
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer: FKM, FFKM, EPDM, AFLAS, NBR
- Metal Part: SS304, SS316, Duplex, Hastelloy C, 904L
- Applicable Pump Models:
FT - CARTEX SN Cartridge Seals
- Operating Limits: ● Shaft size: 24mm - 100mm
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer: FKM, FFKM, EPDM, AFLAS, NBR
- Metal Part: SS304, SS316, Duplex, Hastelloy C, 904L
- Applicable Pump Models:
FT - CARTEX DN Cartridge Seals
- Operating Limits: ● Temperature:-20℃ - +220℃ ● Pressure：≤ 25bar ● Speed: ≤ 16m/s ● Shaft size: 25mm - 100mm
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer:FKM, FFKM, EPDM, AFLAS, NBR
- Metal Part: SS304, SS316, Duplex, Hastelloy C, 904L
- Applicable Pump Models:
FT - SAF Cartridge Seals
- Operating Limits: ● Temperature:-20℃ - +220℃ ● Pressure：≤ 25bar ● Speed: ≤ 16m/s ● Shaft size: 25mm - 200mm
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer: FKM, FFKM, EPDM, AFLAS, NBR
- Metal Part: SS304, SS316, Duplex, Hastelloy C, 904L
- Applicable Pump Models: Widely applied in Pulp & Paper industry
FT - EMU Cartridge Seals
- Operating Limits: ● Temperature:-30℃ - +200℃ ● Pressure：≤ 15bar ● Speed: ≤ 20m/s ● Shaft size: 30mm - 60mm
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer: VITON, EPDM, NBR
- Metal Part: SS304, SS316
- Applicable Pump Models: Equivalent To: Wilo EMU
FT - 5610 Cartridge Seals
- Operating Limits: ● Temperature:-20℃ - +220℃ ● Pressure：≤ 21bar (Up to 75mm/3.0") ; ≤ 13bar (≥ 75mm/3.0") ● Speed: ≤ 10m/s ● Shaft size: 24mm - 140mm; 1” - 5.5”
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer: FKM, FFKM, EPDM, AFLAS, NBR
- Metal Part: SS304, SS316, Duplex, Hastelloy C, 904L
- Applicable Pump Models: Equivalent To: John Crane 5610 / 5610Q
FT - STJK Cartridge Seals
- Operating Limits: ● Temperature:-40℃ - +120℃ ● Pressure：≤ 15bar ● Speed: ≤ 20m/s ● Shaft size: 25mm - 100mm
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer: FKM, FFKM, EPDM, AFLAS, NBR
- Metal Part: SS304, SS316, Duplex, Hastelloy C, 904L
- Applicable Pump Models: Equivalent To: John Crane 5610 / 5610Q
FT - CONVERTOR II Cartridge Seals
- Operating Limits: ● Temperature:-20℃ - +220℃ ● Pressure：≤ 25bar ● Speed: ≤ 15m/s ● Shaft size: 24mm - 100mm / 1.0" - 4.0"
- Materials:
- Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
- Elastomer: FKM, FFKM, EPDM, AFLAS, NBR
- Metal Part: SS304, SS316, Duplex, Hastelloy C, 904L
- Applicable Pump Models: Equivalent To: AESSEAL CONVERTOR II
FT - CONVERTOR II Cartridge Seals
- Operating Limits
- Materials:
- Seal Rings:
- Elastomer:
- Metal Part:
- Applicable Pump Models: Feature: JCS1F is a typical mechanical seal. Our company's JCS1F can perfectly replace original John Crane JCS1F mechanical seal.
FT - Bornemann Cartridge Seals
- Operating Limits
- Materials:
- Seal Rings:
- Elastomer:
- Metal Part:
- Applicable Pump Models: Feature: The cartridge mechanical seals are applied in Bornemann Lobe Pumps. This is a double cartridge mechanical seal that can be used in extreme working conditions such as high temperature and high pressure.
