MFLC12 Mechanical Seal For Cryostar Pumps

  • Operating Limits: Description: Type : MFLC12 is Metallic Bellow Seal for Cryogenic Application, This mechanical seal is applied in Cryostar Pumps, can replace Bugmann MFLC12.
  • Materials:
  • Special Features : Seal Rings: Meets liquid oxygen (LOX) safety standards : Anti-spark sleeve and retaining ring, Reduced power consumption, Minimal product loss, Available as cartridge seal
  • Elastomer: VITON, EPDM, NBR
  • Metal Part: SS304, SS316
  • Applicable Pump Models: Industrial liquid gases, including : Oxygen, Nitrogen, Argon, Carbon Di Oxide

JC 609 Metal Bellows Seals

  • Operating Limits:Temperature:-75℃ - +350℃ ● Pressure：­­≤ 20bar ● Speed: ­≤ 25m/s ● Shaft size: ­1"- 4"
  • Materials:
  • Seal Rings: A, B, Q1/12, Q2/22, U1/12, U2/22
  • Elastomer: VITON, EPDM, NBR, FFKM, AFLAS
  • Metal Part: SS304, SS316, 4J42, 2CR13, AM350, Hastelloy C, Inconel 718
  • Applicable Pump Models: Equivalent To: John Crane Type 609

JC 680 Metal Bellows Seals

  • Operating Limits: Temperature:-20℃ - +350℃ ● Pressure：­­≤ 20bar ● Speed: ­≤ 25m/s ● Shaft size: ­0.75"- 6" / 18mm - 150mm
  • Materials:
  • Seal Rings: A, B, Q1/12, Q2/22, U1/12, U2/22
  • Elastomer: VITON, EPDM, NBR, FFKM, AFLAS
  • Metal Part: SS304, SS316, 4J42, 2CR13, AM350, Hastelloy C, Inconel 718
  • Applicable Pump Models: Equivalent To: John Crane Type 680

MFLWT80 Metal Bellows Seals

  • Operating Limits:Temperature:-40℃ - +380℃ ● Pressure：­­≤ 25bar ● Speed: ­≤ 20m/s ● Shaft size: 16mm - 100mm
  • Materials:
  • Seal Rings: A, B, Q1/12, Q2/22, U1/12, U2/22
  • Elastomer: VITON, EPDM, NBR
  • Metal Part: SS304, SS316, 4J42, 2CR13, AM350, Hastelloy C, Inconel 718
  • Applicable Pump Models: Equivalent To: Eagle Burgmann Type MFLW80T

MFL85N Metal Bellows Seals

  • Operating Limits: ● Temperature:-20℃ - +350℃ ● Pressure：­­≤ 21bar ● Speed: ­≤ 23m/s ● Shaft size: 16mm - 100mm
  • Materials:
  • Seal Rings: A, B, Q1/12, Q2/22, U1/12, U2/22
  • Elastomer: VITON, EPDM, NBR, FFKM, AFLAS
  • Metal Part: SS304, SS316, 4J42, 2CR13, AM350, Hastelloy C, Inconel 718
  • Applicable Pump Models: Equivalent To: Eagle Burgmann Type MFL85N
